The dual side focusing structure with 250° rotation cycle and the quick throw zoom lever make zooming in and out quick and convenient, helping you acquire targets faster. The dual lever return to zero QD mount makes mounting and unmounting quick and easy.
Sensor Specifications
- Type: VOx Uncooled
- Resolution, pixels: 640×512
- Pixel Pitch, µm: 12
- NETD, mK: ≤20
- Frame Rate, Hz: 60b
Optical Specifications
- Objective Lens,mm: 60 F1.0
- Optical Zoom: 3x
- Field of View, degrees / yd @ 100 yd: 7.3°×5.8°
- Digital Zoom: 1x to 6x, stepped
- Eye Relief: 60mm
- Diopter Adjustment, D: -5 to +2
- Detection Range, m/yd: 3280
Display Specifications
- Type: OLED
- Resolution, pixels: 2560 x 2560
LRF Specification
- Type, nm: 905
- Max Range, yd: 1200
Wi-Fi
- Wireless Protocol: Wi-Fi
- Frequency, GHz: 2.4GHz
- BT Frequency, MHz :2402~2480
Video Recorder
- Video / Photo Resolution, pixels: 1280×1280
- Video / Photo Format: .mp4 / .jpg
- Built-in Memory, GB: 64
Physical Specifications
- Degree of Protection, IP code: IP67
- Operating Temperature Range, °F: -4 to +122
- Weight, lb: 2.9
- Dimensions, inch: 10.3×3.3×3.8
Connections and Compatibilities
- Battery Type: 18650×2
- Capacity, mAh: 3800
- Operating Time on Battery Pack (at t=72°F), h8
- External Power Supply, V: 5V (Type C USB)
- Max Recoil Power on Rifled Weapon (Eo), g/Joules: 1000g/6000Joules
